| Fluke
|
|
|
|
장 비 명
|
AC/DC Current Clamp
|
|
모
델 명
|
80i-110s
|
|
제
조 사
|
Fluke
|
| |
|
|
|
|
|
장비 사양 |
|
|
|
|
The 80I-110s is compatible with any Fluke ScopeMeter Test Tool, Power Harmonics Analyzer, Oscilloscope, Multimeter, or other voltage measurement device that has the following features: BNC input connectors or if using a meter convert the banana plugs to a BNC connector using the adapter PM9081/001.
Current Range:
0.1 to 100A DC or 0.1 to 70A AC
Basic Accuracy (DC to 1kHz):
사양;
100mV/A setting: 50mA to 10A +/- 3% of reading + 50mA
10mV/A setting: 50mA to 40A +/- 4% of reading + 50mA
40A to 80A +/- 12% of reading + 50mA
80 to 100A +/- 15% of reading
Output Signal:
10A range: 100mV/A | 100A range: 10mV/A
Bandwidth:
1Hz to 20kHz
Working Voltage:
600V AC rms
Maximum Conductor Size:
11.8 mm (.46 inch) diameter
Safety Rating:
IEC 1010 and CSA-C22.2 No. 1010-1 Installation Category II, Working Voltage 600V
|
|
|
|
|
